Metallographic Grinding & Polishing Machine PC-20
Stable and easy‑operating single‑disk metallographic grinding and polishing machine with three fixed speeds, stepless adjustment, and durable engineering plastic body for reliable sample preparation.
The Metallographic Grinding & Polishing Machine PC-20 is a versatile single‑disk grinding and polishing device for laboratory metallographic sample preparation. It features a one‑piece environmental engineering plastic casing with a smooth surface, scratch resistance, and easy maintenance. The conical disc system enables fast disc replacement and cleaning. With stepless speed regulation and three customizable fixed speeds, the machine supports quick switching between grinding and polishing. Stable rotation, low noise, large‑diameter anti‑clogging drain pipe, and adjustable water flow ensure high efficiency and consistent sample quality.
2. Key Selling Points
- Integrated environmental engineering plastic body, smooth, durable and easy to repair scratches.
- Conical disc system for quick replacement and easy cleaning.
- Large‑diameter drain pipe to prevent blockage.
- Stable chassis rotation with low vibration and low noise.
- Stepless speed adjustment for precise speed control.
- Three fixed speeds for quick access to common working speeds.
- One‑key switch between grinding and polishing modes.
- Adjustable water flow for better grinding and polishing performance.
- Rotation direction (clockwise / counterclockwise) is adjustable.
- Equipped with emergency stop button for safe operation.
3. Technical Parameters
| Item | Specification |
|---|---|
| Working disc diameter | 200mm / 230mm |
| Speed range | 100–1000 r/min |
| Three fixed speeds | S1=300r/min, S2=500r/min, S3=800r/min (customizable) |
| Rotation direction | Clockwise / Counterclockwise adjustable |
| Motor power | 550W |
| Voltage / Frequency | AC220V 50Hz (N+L1+PE) |
| Emergency stop | Emergency stop button |
| Water pressure | 1–10 bar / 0.1–1 MPa |
| Inlet pipe | Φ8 mm, length 2 m |
| Drain pipe | Inner diameter Φ40 mm |
| Operation panel | Mechanical buttons |
| Operating temperature | 5–40 °C |
| Operating humidity | 0–95% RH |
| Dimensions (L×W×H) | 720×685×320 mm |
| Weight | 50 Kg |
4. Applicable Materials
Steel, stainless steel, cast iron, aluminum alloy, copper alloy, titanium alloy, cemented carbide, welded parts, castings, forgings, composite materials, ceramics, coatings, electronic materials, PCB, thin films and other metallographic samples.
5. Standard Configuration
| No. | Configuration Content |
|---|---|
| 1 | 1 set of PC-20 main machine |
| 2 | 1 piece of working disc (200mm or 230mm) |
| 3 | 1 set of mechanical control panel |
| 4 | 1 set of conical disc system |
| 5 | 1 set of water supply and drainage system |
| 6 | 1 set of splash guard |
| 7 | 1 set of emergency stop button |
| 8 | 1 set of power cable |
6. Optional Accessories
- Metallographic abrasive papers (various grits)
- Polishing cloths (flannel, nylon, suede, silk, damping cloth, etc.)
- Diamond spray, suspension, polishing paste
- Alumina / silica polishing solution
- Magnetic support disc & adhesive disc
- Sample holders and clamps
- Water cooling system
7. Application Cases
- Metallographic sample preparation for automotive parts, gears, bearings, fasteners
- Aerospace alloy material grinding and polishing
- Welded structure and heat treatment sample analysis
- PCB, electronic components and connector sample preparation
- Quality control and material research in factories, laboratories and research institutes
